Rocket Prism 5AC

Dimensions 88 x 40 x 230 mm (3.5 x 1.6 x 9.1")

Weight 400 g (14.1 oz)

Enclosure material Die-cast aluminum

Mounting Pole mounting (Kit included)

Wind loading 342.5 N at 200 km/h (77 lbf at 125 mph)

Hardware

Networking interface (1) GbE RJ45 port

RF connectors (2) RP-SMA (Waterproof)

(1) GPS (Waterproof)

Power method Passive PoE 2-pair (4, 5+; 7, 8 return)

Power supply 24V, 1A gigabit PoE adapter (Included)

Supported voltage range 18—27V DC

Max. power consumption 9.5W

LEDs (4) Signal strength: software-adjustable to correspond to custom RSSI levels

GPS, LAN, power

Shock and vibrations ETSI300-019-1.4

Ambient operating temperature -40 to 80° C (-40 to 176° F)

Ambient operating humidity 5 to 95% noncondensing

Certifications CE, FCC, IC, RoHS

NDAA Compliant Yes

Software

Modes Access Point, station

Channel sizes

PtP mode

PtMP mode

10/20/30/40/50/60/80 MHz

10/20/30/40 MHz

Services Web server, SNMP, SSH server, telnet , ping watchdog, DHCP, NAT, bridging, routing

Utilities airMagic, airView, antenna alignment tool, discovery utility, site survey, ping, traceroute, speed test

Distance adjustment Dynamic Ack and Ackless mode

Power adjustment Software adjustable UI or CLI

Security

WPA2 AES only

QoS

Supports packet level classification WMM and user customer level: High/Medium/Low

Statistical reporting

Up time, packet errors, data rates, wireless distance, Ethernet link rate

Ubiquiti specific features

30/50/60 MHz Channels, airMAX ac mode, traffic shaping with burst support, discovery protocol, frequency band offset, Ackless mode

Operating Frequency (MHz)

Worldwide 5150–5875 MHz
